Bộ chuyển mạch công nghiệp Unmanaged SFC300-POE
Switch Soltech

Bộ chuyển mạch công nghiệp Unmanaged SFC300-POE

✓ Chính hãng 100%
⚙ Bảo hành chính hãng
⏱ Hỗ trợ 24/7
Yêu cầu báo giá 0978 994 988
Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3U 100Base-TX/100Base-FX IEEE 802.3af Power Over Ethernet Standards
RJ45 Ports POE 10/100Mbps TP 4-Ports Auto MDI/MDI-X UTP/STP Cat. 3, 4, 5, 6 Cable EIA/TIA-568 100-ohm (Transmission Distance 100m) Provides DC 48V Power Over RJ-45 Ethernet Cable to Devices with Ethernet Port
Fiber Ports 100Mbps-FX, SFP 2-Slots Multi-mode : 62.5/125㎛ (2km) Single-mode : 9/125㎛ (~ 100km)
LED Indication Per unit : Power, Fault TX Port (Link/Act, FDX/HDX, Speed) FX Port (Link/Act, FDX/HDX, Speed)
Throughput 100Mbps
MAC Address 2K MAC Address table
PoE 15.4Watt (MAX 60W) per port
Humidity 5 ~ 95% (Non-condensing)
Installation DIN-Rail, Panel mounting
Temperature Operating : - 40℃ ~ 80℃ Storage : - 45℃ ~ 85℃
Humidity 5 ~ 95% (Non-condensing)
Power Supply DC 48V
Dimensions 55mm(W) x 120mm(D) x 150mm(H)
  • 802.3af PoE 15.4 Watt (Max. 60W)
  • DIN-Rail installable
  • Power polarity protection circuit built-in
  • DC 48V (terminal block) power supply method
  • IEEE802.3af Power Over Ethernet / PSE
  • 4-Ports (PoE 802.3af) + SFP 2-Slots industrial optical switch
  • 100Mbps PoE switch suitable for industrial environment

    Description

    Industrial PoE switch that can withstand extreme environments

    Industrial PoE switch that can endure severe environment allowing to provide high maintenance. speed reliable network to rough industrial field smart city, factory, plants, apartment and buildings. Web-based management allows the user to have convenient managing of switch.

    Quality verificated 100% Made In Korea

    SFC300-PoE is a Made in Korea optical converter with reliable internal materials. Check all processes from production to delivery and use them with confidence.

    100Mbps PoE 4 Ports, 100Mbps 2 SFP Slots switch

    Various equipment such as CCTV, Webcam, Internet modem, IP telephones can be installed for various field environments.

    Product Details

    Construction

    Dimensions

    Compare Product Lines

    SFC300T SFC300-SCS SFC300-SCS2 SFC300-SCM SFC300-SCM2 SFC300-PoE SFC300-SFP SFC300GS SFC310C
    RJ45Port 4 TP(100Mbps) 4 TP(100Mbps) 4 TP(100Mbps) 4 TP(100Mbps) 4 TP(100Mbps) 4 TP(100Mbps) 4 TP(100Mbps) 2 TP(1Gbps) 1 TP(1Gbps)
    SFP/SFP+ Port – 1 SC(100Mbps) 2 SC(100Mbps) 1 SC(100Mbps) 2 SC(100Mbps) 2 SFP(100Mbps) 2 SFP(100Mbps) 2 SFP(1Gbps) 1 SFP(1Gbps)
    Switch Fabric 0.8Gbps 1Gbps 1.2Gbps 1Gbps 1.2Gbps 1.2Gbps 1.2Gbps 8Gbps 4Gbps
    Throughtput 0.6Mpps 0.7Mpps 0.9Mpps 0.7Mpps 0.9Mpps 0.9Mpps 0.9Mpps 5.9Mpps –
    MAC Table 1K 1K 1K 1K 1K 1K 1K 4K 2K
    Jumbo Frame – – – – – – – 9K 9K
    Operating Temperature -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃ -40 ~ 80℃
    Power Input DC 12 ~ 56V DC 12 ~ 56V DC 12 ~ 56V DC 12 ~ 56V DC 12 ~ 56V DC 48 ~ 56V DC 12 ~ 56V DC 12 ~ 56V DC 12 ~ 56V
    Power Consumption AC 3.7W AC 4.2W AC 4.3W AC 4.2W AC 4.3W AC 65W AC 5.3W AC 4.2W AC 2.1W
    PoE Capacity – – – – – PoE Max. 60W – –
    Installation Method DinRail Mount DinRail Mount DinRail Mount DinRail Mount DinRail Mount DinRail Mount DinRail Mount DinRail Mount DinRail Mount
    Dimension (WxDxH) 42 x 87 x 112 (mm) 42 x 87 x 112 (mm) 42 x 87 x 112 (mm) 42 x 87 x 112 (mm) 42 x 87 x 112 (mm) 41 x 103 x 133 (mm) 41 x 103 x 133 (mm) 39 x 107 x 97 (mm) 33 x 77 x 110 (mm)
